AC Circuit Breaker Panel – With 30+ position White Circuit Breakers
Panel Dimensions: Custome
Panel Material: Matte Plexiglass
- Assembled with Digital Multi Meter 0-16 volt
- Blue Sea Systems,
- 5 Amp, A-series circuit breakers (Carling Technologies)
- 10 Amp, A-series circuit breakers (Carling Technologies)
- 15 Amp, A-series circuit breakers (Carling Technologies)
- 20 Amp, A-series circuit breakers (Carling Technologies)
- 25 Amp, A-series circuit breakers (Carling Technologies)
- 30 Amp, A-series circuit breakers (Carling Technologies)
- Label set included
- All circuit breaker labels are backlit with LED
- 2-year warranty
Assembled With:
- LCD Panel AC Power Meter with AC current transformer
- Blue Sea A-Series Circuit Breakers – 5A,10A,15A,20A,25A,30Amp
- LED Light Indicators
- Blue Sea DC label Set
- LED strip lights to back-light labels
Blue Sea Systems A-Series Circuit Breakers Features:
- Meets American Boat and Yacht Council (ABYC) standards
- The industry standard circuit breaker for Blue Sea Systems’ electrical panels
- Combines swtiching and circuit protection into a single device
- “Trip Free” design cannot be held “ON” during fault current condition
AC Meter Specifications:
- Dual measurement of AC voltage, AC current with AC current transformer (It can’t be used for measuring the AC power converted from a DC power with an inverter)
- Voltage Measuring Range: AC 80 ~ 260V
- Current Measuring Range: AC 0 ~ 100A
- Active Power Measuring Range: 0 ~ 22kW
- Energy Measuring Range: 0 ~ 9999kWh
- Operating Temperature: -10 ºC ~65 ºC
- Operating Humidity: 35~85% RH
- Dimensions: 9cm * 5cm * 2.45cm/3.54″ * 1.97″ * 0.96″
Designed & Assembled In America
