| Specifications |
| Switch Type |
Single Circuit ON-OFF |
| Color |
Red |
| Switch Positions |
2 |
| Battery Combine |
No |
| Alternator Field Disconnect |
No |
| Maximum Voltage |
48V DC |
| Terminal Stud Torque |
140 in-lb (15.82 Nm) |
| Continuous Rating |
350A |
| Intermittent Rating |
600A (5 min) |
| Cranking Rating 30 sec |
1200A |
| Battery Inputs |
1 |
| Cable Clearance For 4/0 AWG Cables |
1.10in (27.94 mm) |
| Cable Size to Meet Ratings |
4/0 AWG (120mm²) |
| Mounting Holes |
Accept 1/4″ (M6) Screw |
| Stud Material |
Tinned Copper |
| Terminal Stud Size |
3/8″ – 16 (M10) |
| Weight |
1.30lb (0.59 kg) |
