Description
Cummins C6.0 |Dual Station| 2 Engine Instrument Panels – 4 OceanLink Veratron (VDO) Gauges – PLUG AND PLAY to Original Wiring Harness
Fully-Wired Cummins Plug and Play
Panel Material: Marine Acrylic, Polycarbonate, Marine Plexiglass
Black Panel / Black OceanLink Gauges (Made in Switzerland)
***Also available in White Panel / White Gauges or any combination.***
Main Station Panel
- OceanLink 3000 RPM Programmable Tachometer with Digital Multi-Function LCD Display and NEMA Converter Built-In
- OceanLink Engine Coolant Water Temp Gauge
- OceanLink Engine Oil Pressure Gauge
- OceanLink 12v Voltmeter
- Cummins 8 pin plug (PLUG AND PLAY)
• 4 Analogue Input (RPM, Temperature, Oil Pressure, Volt)
• Programmed for Cummins C6.0
• NMEA 2000® Output/Input
• Alarm for Temperature, Oil Pressure and high/low voltage.
• Protection Rating IPX7
Second Station Panel
- OceanLink 3000 RPM Programmable Tachometer with Digital Multi-Function LCD Display and NEMA Converter Built-In
- OceanLink Engine Coolant Water Temp Gauge
- OceanLink Engine Oil Pressure Gauge
- OceanLink 12v Voltmeter
- Cummins 8 pin plug (PLUG AND PLAY)
• 4 Analogue Input (RPM, Temperature, Oil Pressure, Volt)
• Programmed for Cummins C6.0
• NMEA 2000® Output/Input
• Alarm for Temperature, Oil Pressure and high/low voltage.
• Protection Rating IPX7
Kit Includes:
- Tw0 (2) Fully Wired Instrument Panels for Main and Second Station with 4 Marine-Grade Gauges
- Engine Alarm Warning LED
- Cole Hersee Push Button Switch for Engine Stop
- Cole Hersee Ignition Key (Off, Stop, Ignition, Start) – (Main Panel)
- Cole Hersee Push Button Switch for Engine Start – (Second Station Panel)
- Loud Piezo Siren Alarm
- Panel completely wired to Cummins plug (PLUG AND PLAY)
Benefits of using OceanLink™ Gauges:
OceanLink™ 52MM Gauges are Connected Directly to any OceanLink™ Master Unit Using the Patented EasyLink Serial Bus Connection.
EasyLink Data Connection makes Installation Easy and Cost-Effective. Satellite Instruments for Further Dynamic Measurement Values Receive Updates from the Central Instrument Every 20 ms.
• Easy and Effective use
• Perfectly Readable Engine Monitoring Thanks to Increased Performance Presentation
• EasyLink Data Connection and the Plug & Play Solution Provide a Flexible Installation of the Panel, Front, and Flush-Mounted Instruments
• Decades of Experience Guarantee a Fully Reliable, Modern Navigation and Engine Monitoring System with NMEA 2000®
• Solid Housing Design Completely Sealed Against Dust and Highly Water-Resistant (IPX7 Front and Rear)
• High-Quality Precision Instruments Designed in Switzerland
- Temperature Sending Unit
- Oil Pressure Sending Unit
*Engine Wiring Harness (Optional Add-On)
*Engine Wiring Harness Y Adaptor (Optional Add-On)
