Description
Isuzu Engine Instrument Panel – 3 Premier Gauges
Fully-Wired / Ready to Install
Product Description
Panel Material: Marine Acrylic, Polycarbonate, Marine Plexiglass
Dimensions: 7 5/8″ x 6 3/4″
Black Panel with White or Black Premier Gauges
Fog resistant Marine Grade Gauges:
- 4000 RPM Programmable Tachometer with Digital Hour Meter 7 Character LCD Display
- Engine Coolant Water Temp Gauge 40-110 °C or 100-240 °F
- Engine Oil Pressure Gauge 0-80 PSI or 0-5 Bar
Kit Includes:
- Fully Wired Instrument Panel with 3 Marine Grade Gauges
- Cole Hersee Sealed Ignition Key Switch
- Piezo Siren Alarm Dual Sound
- Temperature Sending Unit
- Oil Pressure Sending Unit
*Sending Units may vary depending on engine(s)*
*Engine Wiring Harness (Optional Addon): Lengths of 15ft and 25ft.
*If you need any other length, no problem. Just give us a call!*
- This product offers a unique flame retardant polyvinyl chloride compound (VW-1) and is moisture, abrasion, acid, diesel fuel, and oil resistant. It is extremely flexible & easy to work with.
- Single Cable with 12 Marine Grade Wires – 14/16 AWG
- Temperature: 105°C dry, 75°C wet
- Voltage: 600 Volts
- Stranding: Class K 30 Gauge Tinned Copper
- Standard: UL 1426 & UL Listed BC-5W2
- Connected to the panel via terminal strip
*If Engine Octopus is purchased along with the Wiring Harness then the opposing end will have a 12-Pin Deutsch Connector*
Features and Benefits of Cole Hersee Sealed Ignition Key Switch:
- Engineering thermoplastic construction
- Fully sealed contact area using O-rings and ultrasonic welding
- Integrated Sealed Deutsch Connector Interface
- Anti-restart and spring return options available
- Tested to SAE J259 for ignition switches
- Supplied with two matching keys, with or without boot
- Custom logo can be molded on the boot
- Multiple key codes or keyed alike available
- Key is removable only at the ‘Off’ position
An extensive series of ignition switches can also be used as rotary switches. Suitable for a broad range of voltages: 10A at 12V, 5A at 24V, 3A at 36V and 2A at 48V DC. Made of rugged engineering grade plastic, these switches stand up to mechanical shock and vibration, and will not corrode or rust. This switch has an integrated Deutsch-type socket to make electrical connection quick and easy and to exclude moisture and dust. UL-tested and recognized to SAE J259 for ignition switches. Contacts are sealed front and back to IP67 (with connector installed). Many options available with regard to position, spring return, key boot style and marking, actuator interface and length, and anti-restart features.
Marine Grade Wire & Features:
- USCG / NMEA specification Copper tinned wire
- flexible cable water and oil resistant
- 10″ to 12″ Pigtail Harness connected to 12 position terminal strip
12 Circuit 30 Amp Terminal Strip Features:
- Closed-back design completely insulates power from the mounting surface
- Each screw pair is one isolated circuit
- Jumpers allow the creation of common circuits
Additional Features:
- Marine-grade push button switch (Engine Stop, or Pre-heat, or both if need it)
- Senders and Accessories not Included
- Engraved with Engine Name (optional your boat Name)
- 2 LED lights Piezo Siren Alarm
Additional Options Available:
- Black or White Panel.
- 24v System Available (optional)
- Customize Panel Size, Gauges, Design, and Switches — Just contact us (extra charge applicable)
Please specify your requirements
If you have any technical questions please feel free to call or email us.
All panels are made in the USA by AC DC Marine Inc. Torrance, California
