Description
Westerbeke Marine Engine Instrument 4 Offshore Gauges
Fully-Wired / Ready to Install
Dimensions: 11″ x 7″
Panel Material: Marine Acrylic, Polycarbonate, Marine Plexiglass
Black Panel /Black OffShore Gauges
Fog-Resistant Marine Grade Gauges:
- OffShore 4000 RPM Programmable Tachometer with Digital Hour Meter 7 Character LCD Display
- OffShore Engine Coolant Water Temp Gauge 120-250°F/50-120°C
- OffShore Engine Oil Pressure Gauge 0-80 PSI/0-5 Bar
- OffShore Voltage Meter 12v or 24v
• 316 Stainless Steel Bezels with Convex Glass
• Selection of Red or Yellow Backlight, without Connector Cables
• Connect Directly without Extra Resistors for 12V/24V Working Voltage
• Front Side Protection Rating – IP67 ; Backside Protection Rating – IP65
Kit Includes:
- Fully Wired Instrument Panel with 5 Marine-Grade Gauges
- Cole Hersee Sealed Ignition Key Switch
- Piezo Alarm Siren
- Alarm LEDs
Features and Benefits of Cole Hersee Sealed Ignition Key Switch:
- Engineering Thermoplastic Construction
- Fully Sealed Contact Area Using O-Rings and Ultrasonic Welding
- Integrated Sealed Deutsch Connector Interface
- Anti-Restart and Spring-Return Options Available
- Tested to SAE J259 for Ignition Switches
- Supplied with Two Matching Keys, with or without Boot
- Custom Logo can be Molded on the Boot
- Multiple Key Codes or Keyed Alike Available
- Key is Removable only at the ‘Off’ Position
An Extensive Series of Ignition Switches can also be Used as Rotary Switches. Suitable for a Broad Range of Voltages: 10A at 12V, 5A at 24V, 3A at 36V and 2A at 48V DC. Made of Rugged Engineering-Grade Plastic, these Switches Stand up to Mechanical Shock & Vibration, and Will not Corrode or Rust. This Switch has an Integrated Deutsch-Type Socket to Make Electrical Connection Quick and Easy & to Exclude Moisture and Dust. UL-Tested & Recognized to SAE J259 for Ignition Switches. Contacts are sealed front and back to IP67 (with connector installed). Many Options Available with Regard to Position, Spring-Return, Key Boot Style and Marking, Actuator Interface and Length, & Anti-Restart Features.
- Temperature Sending Unit
- Oil Pressure Sending Unit
*Sending Units May Vary Depending on Engine(s)*
*Engine Wiring Harness (Optional Add-On): Lengths of 15ft and 25ft.
*If You Need Any Other Length, No Problem — Just Give Us a Call!*
- This Product Offers a Unique Flame Retardant Polyvinyl Chloride Compound (VW-1) and is Moisture Abrasion, Acid, Diesel Fuel, and Oil-Resistant. It is Extremely Flexible & Easy to Work With.
- Single Cable with 12 Marine Grade Wires – 14/16 AWG
- Temperature: 105°C Dry, 75°C Wet
- Voltage: 600 Volts
- Stranding: Class K 30 Gauge Tinned Copper
- Standard: UL 1426 & UL Listed BC-5W2
- Connected to the Panel via Terminal Strip
*If Engine Octopus is Purchased Along with the Wiring Harness, The Opposing End Will Have a 12-Pin Deutsch Connector*
Marine-Grade Wire & Features:
- USCG / NMEA Specification Copper-Tinned Wire
- Flexible Cable – Water and Oil-Resistant
- 10″ to 12″ Pigtail Harness Connected to 12-Position Terminal Strip
