Description
VDO Switzerland Marine 2-1/16″ (52mm) Viewline Pyrometer 250°-1650° F Black Dial and Bezel
ViewLine 52 mm Pressure Gauges are equipped with a red warning LED as a standard. The warning point depends on the chosen pressure sensor with warning contact or can be controlled by installing a make-point switch.
Antifog plastic double lens, maximum precision and stylish design.
Specifications:
- 8 pole Tyco / Hirschmann MQS plug
- +/- 3.6° angle degree accuracy over the entire display range
- Operating voltage 8 – 32 V
- Integrated warning alarm
- Input signal: standard Ω values
- Optional make-point switch can be connected
- Reverse polarity protection
- Front side protection rating IP67
- 52 mm installation diameter
- 50 mm installation depth
We have a variety of Bezels (black & chrome triangle) Please, contact us for more information.
[pdf-embedder url=”https://acdcmarineinc.com/wp-content/uploads/2020/09/A2C59519498-Pyrometer-12_24.pdf” title=”A2C59519498 — Pyrometer 12_24″]
